The OP 201 circular saw is a time-tested machine with the possibility of versatile use in carpentry workshops and in the workshops of demanding do-it-yourselves. This saw has the same construction of the unit as large formatting saws. The unit is a tilt able up to 45 degrees. and is suspended on crescents which always ensure the precise position of the saw blade relative to the fixed table. The cast-iron work table has a milled fine corduroy, thanks to which the machined material slides easily on it. In addition, the table contains two guide T-slots, both to the left and the right of the saw blade. For machining laminated boards, the machine can be equipped with a coupled pre-cutting unit. The machine can be further expanded with a cast iron table with a bearing guide and a single-lever gouging device. The machine stand is equipped with tilting castors.
| Working height of the saw table | 830 mm |
| Work table size | 500×600 (775) mm |
| Formatting table size | 500×250 mmm |
| Saw blade diameter min-max | 200-250 mm |
| Scoring saw wheel diameter | 100 mm |
| Clamping diameter of scoring unit saw blade | 22 mm |
| Spindle speed | 4600 1/min |
| Scoring unit speed | 7000 1/min |
| Tilting the saw blade | 90° – 45° |
| Saw cut with 250 mm blade | 75 mm |
| Saw cut when tilted 45° | 50 mm |
| Cut length | 650 mm |
| Diameter of the main suction nozzle | 100 mm |
| Electric motor | |
| 3×400 V, 50 Hz | 3 kW |
| Speed | 2860 rpm |
| Mortiser | |
| Table size | 360×170 mm |
| Max. diameter of gouging drill | 24 mm |
| Weight | 186 Kg |
